特性：分条机，圆盘剪专用
用途：分条机，圆盘剪专用
| 型号 Part.No | 螺纹规格 Thread Specification G | 最大外径 Outside Diameter D | 高度 Height H | 压力环外径 Outer Diameter Pf Pressure Ring d1 | 压力环内径 Inner Diameter Of Pressure Ring d2 | 行程 Stroke | 最大推力 Max Cylinder Capacity Advance KN | |
| NMS100 | M100*3 | 160 | 45 | 140 | 120 | 2 | 40.8 | |
| NMS110 | M110*3 | 170 | 48 | 150 | 130 | 2 | 44.0 | |
| NMS120 | M120*3 | 180 | 45 | 155 | 140 | 2 | 34.7 | |
| NMS130 | M130*3 | 185 | 45 | 170 | 150 | 2 | 50.2 | |
| NMS140 | M140*3 | 225 | 50 | 200 | 180 | 2 | 59.7 | |
| NMS150 | M150*3 | 240 | 53 | 200 | 180 | 2 | 597 | |
| NMS160 | M160*3 | 250 | 53 | 210 | 190 | 2 | 62.8 | |
| NMS170 | M170*3 | 280 | 60 | 220 | 200 | 2 | 65.9 | |
| NMS180 | M180*3 | 285 | 60 | 250 | 230 | 2 | 75.4 | |
| NMS190 | M190*3 | 285 | 60 | 250 | 230 | 2 | 75.4 | |
| NMS200 | M200*3 | 285 | 60 | 250 | 230 | 2 | 75.4 | |
| NMS210 | M210*3 | 295 | 65 | 270 | 250 | 2 | 81.6 | |
| NMS220 | M220*3 | 300 | 65 | 270 | 250 | 2 | 81.6 | |
| NMS230 | M230*3 | 320 | 65 | 280 | 260 | 2 | 84.8 | |
| NMS240 | M240*3 | 330 | 65 | 300 | 280 | 2 | 91.1 | |
| NMS250 | M250*3 | 340 | 65 | 300 | 280 | 2 | 91.1 | |
| NMS260 | M260*3 | 350 | 65 | 330 | 300 | 2 | 148.4 | |
| NMS270 | M270*3 | 360 | 65 | 330 | 300 | 2 | 1484 | |
